Jharkhand - Design and engineering services for 132/33kV GIS MRSS of Tata Steel Ltd. at Noamundi, Jharkhand for Joda & Noamundi Mines expansion project (on behalf of Siemens Ltd)
The project included preparation of following drawings and design calculations :
1. Protection and metering SLDs of 132/33kV switchyard, 415V LV Switchgear, ACDB, MLDB, ELDB, 220V DCDB, 48V DCDB and Lighting DBs.
2. Switchyard electrical layout, GIS room electrical layout, EKD of switchyard, cable trench layout, DSLP layout, Earthing layout, Lighting layout drawings.
3. Control schematics, interlocking diagrams, terminal plans of BMK, CT & PT JBs.
4. Power and control cable schedule and interconnection diagrams.
5. All electrical design calculations.
6. BOQ of earthing, cabling, lightning protection and lighting materials.
